INTRODUCE :

Kingrail Parts has developed a series of new blocks and tracks based on the latest requirements and technology FEM 1001 and DIN standards 15020.

In all cases, the security at the face of damage is higher than the requirements of the FEM standard. Suspension (hook, cross axle, nut) meets the DIN standard 15411. The hook complies with the DIN standard 15401 and 15402, which is made of STE355 -level forged steel (G -grade, DIN standard 15400). If necessary, you can use alloy 34 CR MO 4, 34 CR Ni Mo 6 and 30 CR Ni Mo 8 (S, T, V Grade).

All linked hooks are equipped with safety bolts to prevent them from being separated from sling. They can be equipped with an anti -rotation system, which can be easily installed without using tools; this can keep the hooks stable. The pulley is made of rolled steel, designed and manufactured by Kingrail Parts, and is equipped with a double -cylindrical roller bearings, which is perfectly located with the special holder. These bearings are lubricated by the lubrication point, each pulley is located at the end of the axle, and properly prevent any possible knocks.

Pay special attention to the shape of the throat when constructing a pulley. The bottom radius (DIN 15601 (R = 0.525 D)) greatly extends the service life of the cable. If the cable is placed correctly in the throat of the pulley, the service life will reach the maximum value. The throat can extend the service life of the cable and can be provided according to the requirements. Due to the type of bearing used, the distance between the pulleys (four or more pulleys and the boat) is very small.

SPECIFICATIONS :

Hook Block Suspensions with Single Hook for Cranes

The hook of DIN15411 standard (with DIN15401 hook).

Material: Hooks is made of forged steel (level P). If necessary, we can use alloy steel (C -level).

All linked hooks are equipped with safety bolts to prevent them from being separated from sling. They can be equipped with an anti -rotation system, which can be easily connected without using a tool, so that the hook is stable.

Technical data

Nº HOOK	a1	b1	b2	b3	b4	c	d5	d6	s	u1	u3	v	BEARING
1	50	50	17,5	-	-	-	25	-	10	39	-	130	51.106
1,6	56	65	17,5	-	-	-	25	-	10	53	-	140	51.107
2,5	63	80	20	22,5	17	8	30	19	10	63,5	-	155	51.108
4	71	90	22,5	25	19	8	35	23	12	71	-	175	51.110
5	80	100	25	27,5	22	8	40	27	15	79,5	-	195	51.112
6	90	125	27,5	30	24	10	45	32	15	90	95	240	51.214
8	100	140	30	35	29	10	50	36	20	98	104	265	51.216
10	112	160	30	35	29	10	55	40	20	110	116	280	51.218
12	125	180	35	42,5	34	10	60	42	25	127	133	315	51.220
16	140	190	35	42,5	36	12	70	50	25	136	143	370	51.222
20	160	200	-	47,5	41	12	80	56	30	150	157	415	51.224
25	180	220	-	49	41	12	90	64	30	166	173	460	51.226
32	200	260	-	59	51	12	100	72	40	188	195	500	51.232
40	224	285	-	65	58	14	110	80	45	208	215	565	51.236
50	250	335	-	65	58	14	125	92	45	224	232	620	51.244
63	280	380	-	71	63	14	140	104	50	260	267	700	51.248
80	315	420	-	72,5	63	14	160	120	50	287	294	800	51.256
100	355	470	-	87,5	77	18	180	136	60	326	333	885	51.260
125	400	510	-	87,5	77	18	200	150	60	365	374	1.000	51.268
160	450	550	-	100	87	18	220	164	70	406	416	1.130	51.272
200	500	610	-	100	87	18	240	184	70	492	501	1.270	51.372
250	560	700	-	110	97	18	260	200	80	552	561	1.440	51.384

Hook Block Suspensions with Double Hook for Cranes

The hook of DIN15411 standard (with DIN15402 hook).

Material: Hooks are made of forged steel (level P). If necessary, we can use alloy steel (C -level). All the hooks are equipped with safety bolts to prevent them from being separated from suspension.

They can be equipped with a anti -rotation system, and they can be easily connected without using tools, so that the hooks are stable.

Technical data

Nº HOOK	a2	b1	b2	b3	b4	c	d5	d6	s	u1	u3	v	BEARING
1	32	50	17,5	-	-	-	25	-	10	39	-	130	51.106
1,6	36	65	17,5	-	-	-	25	-	10	53	-	140	51.107
2,5	40	80	20	22,5	17	8	30	19	10	63,5	-	155	51.108
4	45	90	22,5	25	19	8	35	23	12	71	-	175	51.110
5	50	100	25	27,5	22	8	40	27	15	79,5	-	195	51.112
6	56	125	27,5	30	24	10	45	32	15	90	95	240	51.214
8	63	140	30	35	29	10	50	36	20	98	104	265	51.216
10	71	160	30	35	29	10	55	40	20	110	116	280	51.218
12	80	180	35	42,5	34	10	60	42	25	127	133	315	51.220
16	90	190	35	42,5	36	12	70	50	25	136	143	370	51.222
20	100	200	-	47,5	41	12	80	56	30	150	Overhead Crane Rail Beam Crane Hook Block Assembly Request Quote Please contact us with any concerns or questions you have. Product Categories Crane Wheels Crane Hooks Crane Rails Crane Fasteners Contact Us Email: tyler@kirail.com Phone: +86 15603721115 Recent Posts May 04, 2024 ASCE 30 Rail Dimensions and Manufacturers April 27, 2024 KP80 Rail Specification and Manufacturer April 20, 2024 BS60A Rail Specifications and Manufacturers April 13, 2024 S10 Rail Dimensions and Manufacturers April 06, 2024 12 LB ASCE Rail Dimensions and Manufacturers Kingrail Parts Related Products Kingrail Parts mainly deals in all kinds of crane equipment and crane rail parts, and the product quality has passed various international certifications. All Products Crane Hooks Crane Hooks Kingrail Parts is committed to providing customers with the highest quality products. This long -term promise of quality is reflected in our crane hook series. View More + Crane Hooks Crane Hook Assembly In Kingrail Parts, the production of crane hook assembly strictly in accordance with process requirements, high -quality materials and appropriate forging. View More + Crane Hooks Crane Hook Block Assembly Kingrail Parts can provide the crane bottom hook block assembly according to the different capacity and size requirements of the customer. View More + Crane Hooks Crane Hook Lock Our crane hook locks are suitable for 500kg, 1TON, 2TON, 3TON, 5TON, 8TON, 10TON, 12.5TON, 25ton, 30ton, 50ton, 100ton, 150ton, 175ton, and higher capacity. View More + About Us Company Profile Our Factory Certificate Products Crane Wheels Crane Hooks Crane Rails Crane Fasteners Contact Building 1, Cross-border E-commerce Industrial Park, Comprehensive Bonded Zone, Zhengpugang New District, Maanshan City, Anhui Province,China +86 15603721115 tyler@kirail.com Kingrail Parts is mainly engaged in crane wheels, crane gear wheels, crane wheel assembly, wire rope sheaves, drs wheel block system, crane end trucks, PU wheels, crane rails, crane rail fasteners, etc for 20 years. Copyright © 2022 Maanshan Kingrail Technology Co.,ltd All rights reserved. tyler@kirail.com +86 15603721115
